Command ip address, No ip address, 162 | Dell 28XX specification

Syntax Description

•vlan-id— VLAN ID

Parameters range

•vlan-id— Valid VLAN

Command Modes

Global Configuration

Usage Guidelines

In case the VLAN doesn't exist ("ghost VLAN") only partial list of the commands would be available under the interface VLAN context.

The commands that are supported for VLAN that doesn't exist are:

1IGMP snooping control

2Bridge multicast configuration

Example

In the following example, for VLAN 1, the address is 131.108.1.27 and the subnet mask is 255.255.255.0:

Console (config)# interface vlan 1

Console (config-if)# ip address 131.108.1.27 255.255.255.0

Command: ip address

Use the ip address Interface Configuration mode command to define an IP address for an interface. Use the no form of this command to remove an IP address definition.

ip address ip-address {mask /prefix-length}[default-gatewayip-address]

no ip address

Syntax Description

•ip-address—Specifies the IP address.

•mask—Specifies the network mask of the IP address.

•prefix-length—Specifies the number of bits that comprise the IP address prefix. The prefix length must be preceded by a forward slash (/).

•default-gatewayip-address—Specifies the default gateway IP address.

Parameters range

•ip-address— Valid IP address

•mask —Valid mask

162

Dell PowerConnect 28xx Systems User Guide

Image 162

Dell 28XX manual Command ip address, No ip address, 162
