Page 159

Frame H

VFD-F Series

Frame H

W

W1

JOG	STOP	H1 H
JOG	MODE
RUN	RESET

H2

D

S1

S2

D1

S3

S4

D2

UNIT: mm [inch]

Frame

W

W1

H

H1

H2

H3

D

D1

S1

S2

S3

H1

547.0

480.0

1357.6

1150.0

1119.0

1072.6

360.0

20.00

13.0

13.0

20.00

[21.54]

[18.90]

[53.45]

[45.28]

[44.06]

[42.23]

[14.17]

[0.79]

[0.51]

[0.51]

[0.79]

NOTE

Frame H(H1): VFD1850F43A; VFD1850F43H; VFD2200F43A; VFD2200F43H

C-6	DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
