Power Supplies

NOTE: The following table lists the maximum supported configuration where power supply redundancy is guaranteed.

NOTE: Configurations higher than indicated in the table may change the power supply mode to non-redundant. In non-redundant mode if the power requirement exceeds the installed system power capacity, the BIOS will throttle the CPUs. Also, if CPU Power Capping is enabled, then CPU throttling occurs on configurations that exceed the cap value.

Table 3-1. PSU and Motherboard Support Matrix

PSU One Motherboard Two Motherboards

1100 W	Up to four 140 W
	processors/MLB, twenty-eight

memory modules/MLB, and six 3.5" SAS hard drives/MLB

Up to four 85 W processors/MLB, twelve hard drives/MLB, six memory modules/MLB, and four 3.5" SAS hard drives/MLB

1400 W	Up to four 140 W
	processors/MLB, thirty-two
	memory modules/MLB, and six
	3.5" SAS hard drives/MLB

Up to four 115 W processors/MLB, seven memory modules/MLB, and eight 3.5" SAS hard drives/MLB

Recommended Configuration

Memory - 4G, 1333, 2Rx4X72

Hard Drive - 600G, SAS6, 15K, 3.5, SGT

Full Configuration

This includes full quantity of processors (115 W), memory (-16G, 1333, 2R) and hard drive (600G, SAS6, 15K, 3.5).
