Tightening the wheel nuts, 178 | Holder C 9.92 H manual

Operating Instructions

Maintenance after the first 50 service hours

Tightening the wheel nuts

-Tighten all wheel nuts at the front and rear wheels (1 and 2).

Torque

340 Nm

-Have any damaged parts replaced by your service centre.

Tightening nuts and bolts according to the torque table

-Tighten the nuts and bolts at the variable pumps, axles and engine.

-Tighten the nuts and bolts to the specified torque according to tables in the maintenance data.

C 9.92

2

1
		Bild_S 990_038

178

Image 180

Holder C 9.92 H Tightening the wheel nuts, Tightening nuts and bolts according to the torque table, 178
