Oki B2500 Series manual Cartridge installation, Push the lower panel down until it clicks

Page 15

B2520 / B2540

2Push the lower panel down until it clicks.

PUSH

Cartridge installation

1Stand in front of the machine.

2Push the left and right sides of the cover and pull it towards you at the same time.

2 - Installation

3Setup the back side feed cassette stop by pushing the "PUSH" lever (A).

Then adjust the lateral paper guides to the paper format by pushing lever (B) located on the left guide. Adjust the length paper guide to the paper format by pushing lever (C).

C

A

3Unpack the new cartridge. Gently roll the cartridge 5 or 6 times to distribute the toner evenly inside the cartridge. Thoroughly rolling the cartridge will assure the maximum copies per cartridge.

4 Insert the cartridge in its slot by pushing it until it clicks (last move down) as shown on the picture below.

B

4Take a paper stack, pull the paper off and align it on a flat surface.

5 Close the cover.

5Put the paper stack in the feed cassette (ex: 200 sheets of 80 g/m² paper).

6Put the feed cassette back in its location.

- 10 -

Image 15
