Management and Diagnostic Console
Troubleshooting - Resets Page
Note: To access this page, your organization must have the Remote Management feature enabled. If the feature is not enabled, an error message will display when you click the link to access this page.
The Troubleshooting – Resets page allows you to reset various components associated with the 2Wire gateway network.
Figure 44. MDC Troubleshooting Resets Page
The Clear button in the Local Network field clears all devices from the Local Network list. Doing so will change the configuration settings, and may affect 2Wire gateway operation because it removes all devices (such as computers) from your network.
The Reset button in the DSL Connection field retrains the 2Wre gateway’s DSL connection.
The Reset button in the ISP Connection field resets the PPP connection and/or releases and renews the broadband IP address.
106
