2Wire None manual Management and Diagnostic Console

	Management and Diagnostic Console
Item	Description
Hardware Version	2Wire gateway hardware version.
Hardware Options	The type of peripheral device installed.
DSL Modem Type	ADSL or ISDN.
Current Software	2Wire gateway software version.
Configuration
Key Code	The key code associated with the current
	provisioning settings. The value is
	Unprovisioned if the 2Wire gateway has not yet
	been provisioned.
System Time	The day, month, year, and time; or “Retrieving
	date and time settings from Internet” if not set.
Time Since Last Boot	The time elapsed since the 2Wire gateway was
	last restarted.
Last ID Post	The time elapsed since the 2Wire gateway
	communicated with the configuration server.
Components
DSL Modem	DSL modem software version.
Firewall Rules	Current version of the installed firewall rules
	database.
Application List	Current version of the application list.

Note: The contents of the Components list varies according to service provider-specific information. For example, the Components list may contain language files (such as common_en, common_es, or common_fr); user interface files (such as base_ui); or VoIP files (such as base_voice).

63
