3Com DSA-3CV1100-02

Line Card Management 67

The VDSL Control Menu

To check the VDSL parameters:

1In the Line Card Main Menu (Figure 27), type 4; the VDSL Control Menu

shown in Figure 40 appears.

Figure40 VDSL Control Menu.

2Typ e 1 in the VDSL Control Menu and press <Enter>; the QAM Channel

Status report appears:

VDSL Control Menu

-----------------

1. QAM channel status

2. Read BCM6010 register

3. Write BCM6010 register

4. I2C control

5. VDSL print

0. Return to previous menu

Please Enter your choice:
