Switched Rack PDU

USER’S GUIDE

®

How to schedule an outlet event

1.From the menus of the Web interface, select Switched Rack PDU and then Scheduling.

2.On the Outlet Scheduling page, select how often the event will occur: Daily, Weekly, or One-Time.

If you select Weekly, you can choose to have the event occur once every week or once every two, four, or eight weeks.

3.On the scheduling page, in the Name of event text box, replace the default name, Outlet Event, with a name that will identify your new event.

4.Use the drop-down lists to select the type of event and when it will occur.

The date format for one-time events is mm/dd, and the time format for all events is hh/mm, with the two-digit hour specified in 24-hour time.

An event that is scheduled daily or at one of the intervals available in the Weekly selection continues to occur at the scheduled interval until the event is deleted or disabled.

You can schedule a one-time event to occur only on a date within 12 months of the date on which you perform the scheduling. For example, on June 4, 2004, you could schedule a one-time event on any date from the current date until June 3, 2005.

5.Use the check-boxes to select which outlets will be affected by the action. You can select one or more individual outlets or All Outlets.

6.Click Apply to confirm the scheduling of the event, or Clear to cancel it.

When you confirm the event, the summary page is re-displayed, with the new event displayed in the list of scheduled events.

51
