n
Color / B&W
Resolution
Setting the Scanning Resolution
Resolution is a measure of the fineness or clarity of a printout. Low resolutions may cause text and graphics to have a jagged appearance, while higher resolutions provide smoother curves and lines, crisp text and graphics, and a better match to traditional typeface designs.
You can set the scanning resolution for the documents you send.
The higher the resolution, the higher the quality of output, but the slower the scanning speed.
For black & white sending, set the resolution as follows:
1.Make sure the light above the Color/B&W button is turned off.
❏If not, press Color/B&W to turn it off.
2.Press Resolution.
❏The current resolution setting is displayed.
Ex:
FAX STANDARD
Resolution | 3. Press Resolution to select the resolution setting you want. | ||
| ❏ You can select from the following: | ||
|
|
| |
|
| FAX STANDARD |
|
|
|
|
|
|
| (8 pels/mm ⋅ 3.85 lines/mm) | |
|
| Suitable for most | |
|
|
|
|
|
| FAX FINE |
|
|
|
|
|
|
| (8 pels/mm ⋅ 7.7 lines/mm) | |
|
| Suitable for documents with fine print (smaller than the | |
|
| print in this sentence). | |
Sending Faxes | Chapter 7 |
