User Settings Menu

Name

Description

Settings

DATE & TIME

UNIT TELEPHONE #

UNIT NAME

TX TERMINAL ID

TTI POSITION

Set the date using the numeric buttons. Set the time

–

(24-hour clock) using the numeric buttons.







Enter your fax/telephone number using the numeric

–

buttons (up to 20 digits).







Enter your name or company name you want to appear at

–

the top of each fax page you send (up to 24 characters).







Set the TTI POSITION and TELEPHONE # MARK features.

ON/OFF

Select the position for the identification header (TTI) that

OUTSIDE IMAGE/

appears on every page you send.*

INSIDE IMAGE

OUTSIDE IMAGE: Position the TTI outside the image area.



INSIDE IMAGE: Position the TTI inside the image area.



TELEPHONE # MARKSelect the prefix for the number.

FAX/TEL

SCAN CONTRAST

Select the contrast of the reproduction.

STANDARD/



DARKER: Select for light originals.

DARKER/



LIGHTER: Select for dark originals.

LIGHTER







OFFHOOK ALARM

Enable/disable the off hook alarm. The alarm alerts you

ON/OFF



that the handset or the handset of the telephone or





extension phone is off hook.









VOLUME CONTROL

Select the audio level of the following sounds:

–

CALLING VOLUME

Select the volume of the ring produced when the

1/2/3



MultiPASS C70 detects a voice call.



KEYPAD VOLUME

Select the volume of the keypad touch beep. (For no

0/1/2/3



sound, select “0”.)



ALARM VOLUME

Select the volume of the error alarm sound. (For no sound,

0/1/2/3



select “0”.)



LINE MONITOR VOL

RX CALL LEVEL

TEL LINE TYPE

R-KEY SETTING

Select the volume of the line monitor (sound during

0/1/2/3

dialling). (For no sound, select “0”.)







Select the volume of incoming calls.

HIGH/STANDARD





Select the dialling method the MultiPASS C70 uses to

TOUCH TONE/

match the telephone line type you have.

ROTARY PULSE





Select PBX if your MultiPASS C70 is connected through a

PSTN/PBX

switchboard (PBX). (1 p. 9-2)



If you select PBX, select the PBX type. You can select from



HOOKING, EARTH CONNECTION, and PREFIX.







(Default settings are shown in bold type.)

*Can only be adjusted for black & white transmissions. For colour transmissions, the TTI information is positioned inside the image area.
