TX Settings Menu
Name | Description | Settings |
ECM TX | Enable/disable Error Correction Mode (ECM) during |
| transmission. |
|
|
MID PAUSE SET | Select the length of the pause entered between numbers |
| with the R (Redial)/Pause button. |
|
|
AUTO REDIAL | Select whether the MultiPASS C70 redials if the other |
| party’s line is busy on the first attempt. |
REDIAL TIMES | Select the number of redial attempts. |
REDIAL INTERVAL Select the period of time between redial attempts.
TIME OUT | Enable/disable the TIME OUT feature. |
| ON: Scanning starts 10 seconds after the last number is |
| entered when sending to multiple destinations (five seconds |
| if only sending to one destination). |
| OFF: After entering the last number, press the Start/Scan |
| button, or else the MultiPASS C70 will return to standby |
| mode after 60 seconds. |
|
|
ON/OFF
2SEC (1 to 15)
ON/OFF
2TIMES (1 to 2)*
2MIN. (1 to 99)
ON/OFF
(Default settings are shown in bold type.)
* New Zealand: 1 to 5.
Chapter 14 |
