CHAPTER 10: VLAN

VLAN

Converting Port VLAN to Tag VLAN (continued)

-----------------------------------------------

PORT MODE STATUS

-----------------------------------------------

1		UNTAGGED		UP
2		UNTAGGED		DOWN
6		UNTAGGED		DOWN
7		UNTAGGED		UP
VLAN ID: 10

Name : engineering

Status : Active

-----------------------------------------------

PORT MODE STATUS

-----------------------------------------------

	3		UNTAGGED		DOWN
	4		UNTAGGED		DOWN
	5		UNTAGGED		DOWN
VLAN	ID: 20
Name	: sales

Status : Active

-----------------------------------------------

PORT MODE STATUS

-----------------------------------------------

	3		UNTAGGED		DOWN
	4		UNTAGGED		DOWN
	5		UNTAGGED		DOWN
VLAN	ID: 30
Name	: marketing

Status : Active

-----------------------------------------------

PORT MODE STATUS

-----------------------------------------------

3		UNTAGGED		DOWN
4		UNTAGGED		DOWN
5		UNTAGGED		DOWN

ML1200(tag-vlan)##set-portport=3-5

Port tagging enabled

ML1200(tag-vlan)##set-port port=3-5 tagging id=20 status=tagged

Port tagging enabled

ML1200(tag-vlan)##set-port port=3-5 tagging id=30 status=tagged

Port tagging enabled

ML1200(tag-vlan)##show vlan type=tag

VLAN ID: 1

Name : Default VLAN

Status : Active

(continued on next page)

Enable filtering on the ports required. The software will prompt to ensure that connectivity is not disrupted.

VLANs are now active. However, as the packet traverses VLANs, the packet should be tagged. This is enabled next.

MULTILINK ML1200 MANAGED FIELD SWITCH – INSTRUCTION MANUAL

10–17

Image 179
