Set Port 1 Address Menu
Table 14 shows the Set Port 1 Address menu.
Table 14. Set Port 1 Address
Function | Next Menu |
|
|
Cancel | “Set Address Menu” on page 37 |
|
|
0 | “Options Menu” on page 31 |
|
|
1 | “Options Menu” on page 31 |
|
|
... | “Options Menu” on page 31 |
|
|
F | “Options Menu” on page 31 |
|
|
Note: Supplemental Message Line 1: Change made after Supplemental Message Line
2: next power on
Cancel
Causes the “Set Address Menu” on page 37 to appear.
<value>
Allows the operator to set the address of SCSI port 1. The value can be from
Note: You must select Reset Drive from the Services menu, press the Reset push button or switch off power to the device, then switch on power to activate the new address.
Chapter 3. Drive Operator Panel and Controls 39
