Set Hard Address Menu
Not all values in the range from 00 to FF are valid for an AL_PA. This menu will prompt you with the previous and next valid AL_PA values.
Table 20 shows the Set Hard Address menu.
Table 20. Set Hard Address
Function | Next Menu |
|
|
|
| ||
Cancel | “Fibre Address Menu” on page 40 | ||
|
|
|
|
c | — |
|
|
|
|
|
|
d | — |
|
|
|
| ||
Save Data | “Fibre Address Menu” on page 40 | ||
|
|
|
|
Notes: |
|
|
|
1. Supplemental Message Line 1: <PORT n:26> |
| ||
v n = the port number (0 or 1) |
|
| |
v cd = the last AL_PA value saved (see | and | in Table 3 on page 10) | |
2. Supplemental Message Line 2: <ll - Valid Addr/Invalid - hh > v ll - the next lower valid AL_PA.
v Valid Addr/Invalid = indicates the cd address is valid or invalid. v hh = the next higher valid AL_PA.
Cancel
Causes the “Fibre Address Menu” on page 40 to appear.
cEach enter increments the high order number (c). Selecting this option increments the hexidecimal number. The number wraps from F to 0.
dEach enter increments the low order number (c). Selecting this option increments the hexidecimal number. The number wraps from F to 0.
Save Data
Saves port AL_PA and returns to “Fibre Address Menu” on page 40.
