ICP-CC488 Installation Guide 25.0

Programming Sheets





EN 103

Installer Code

Location

181 to 184

Refer to page 54

Default

1 2 3 4

User Codes

Location

185 to 264

Refer to page 54

User Code 1



Locations 185 to 189

Default



2 5 8 0

10

User Code 2



Locations 190 to 194

Default



15 15 15 15

2

User Code 3



Locations 195 to 199

Default



15 15 15 15

2

User Code 4



Locations 200 to 204

Default



15 15 15 15

2

User Code 5



Locations 205 to 209

Default



15 15 15 15

2

User Code 6



Locations 210 to 214

Default



15 15 15 15

2

User Code 7



Locations 215 to 219

Default



15 15 15 15

2

User Code 8



Locations 220 to 224

Default



0 15 15 15

3

Radio Code 9

Locations 225 to 229

Default



15 15 15 15

2

Radio Code 10

Locations 230 to 234

Default



15 15 15 15

2

Radio Code 11

Locations 235 to 239

Default



15 15 15 15

2

Radio Code 12

Locations 240 to 244

Default



15 15 15 15

2

Radio Code 13

Locations 245 to 249

Default



15 15 15 15

2

Radio Code 14

Locations 250 to 254

Default



15 15 15 15

2

Radio Code 15

Locations 255 to 259

Default



15 15 15 15

2

Radio Code 16

Locations 260 to 264

Default



15 15 15 15

2

User Code Priority Levels













Priority

Description





0



Arm/disarm





1



Arm only





2



Arm/disarm and Open/Close Reports



3



Arm only and Close Report



4



Arm/disarm and code to isolate



6



Arm/disarm, code to isolate, and







Open/Close Reports





8



Arm/disarm and Master Code functions



10



Arm/disarm, Master Code functions, and





Open/Close Reports





12



Arm/disarm, Master Code functions, and





code to isolate





14



Arm/disarm, Master Code functions, code





to isolate, and Open/Close Reports



Day Alarm Zones

Location



265



Refer to page 56

Default

0

1

Zone 1





2

Zone 2





4Zone 3

8 Zone 4

EOL Resistor Value

Location

266

Refer to page 56

0No EOL resistor

11K (brown, black, red)

2 1K5 (brown, green, red)

3 2K2 (red, red, red)

4 3K3 (orange, orange, black, brown) 1%

5 3K9 (orange, white, red)

6 4K7 (yellow, white, red)

7 5K6 (green, blue, red)

8 6K8 (blue, grey, black, brown) 1%

9 10K (brown, black, orange)

10 12K (brown, red, orange)

11 22K (red, red, orange)

12 Reserved

13 Reserved

14 Split EOL (3K3/6K8) with tamper (1K)

15 Split EOL (3K3/6K8) 1% resistors
