Dell C6100 owner manual Installing a Hard Drive Into a Hard-Drive Carrier

Figure 3-4. Removing and Installing a Hard Drive from the Hard-Drive Carrier

1

2

3

1	hard drive	2	screw (4)
3	hard-drive carrier

Installing a Hard Drive Into a Hard-Drive Carrier

CAUTION: Many repairs may only be done by a certified service technician. You should only perform troubleshooting and simple repairs as authorized in your product documentation, or as directed by the online or telephone service and support team. Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came with the product.

1Place the hard drive into the hard-drive carrier. See Figure 3-4.

2Secure the hard drive to the hard-drive carrier with four screws. See Figure 3-4.

58

Installing System Components
