Appendix

Covers

Using this function, you can insert cover and back sheets fed from a different tray to that of the main paper, and print on them.

Reference

For printing methods, see the printer driver Help.

Limitation

To use this function, Collate must be set. Rotating Collate cannot be set.

Note

The cover sheets should be the same size and orientation as the body of the paper.

If Auto Tray Select is set as the paper feed tray for the body paper, the paper will be delivered from a tray containing paper in the K orientation. There- fore, if the cover paper is set to L orientation, the orientation of cover and body will be different.

Cover sheet

6

Prints the first page of the document on the sheet for the cover page.

Print on one side

Prints on one side of the cover sheet only, even when duplex printing is se- lected.

4

4



GCPY016E

Print on both sides

Prints on both sides of the cover sheet when duplex printing is selected.





3





1

3

4

4

2



2

1











GCPY030E

58
