USB Node Registers | National CP3BT26 manual

	Register Name	Size	Address	Access	Value After	Comments
	Register Name	Size	Address	Type	Reset	Comments
				Type	Reset

	WTPTC_1SLOT	Word	0E F1B0h	Write-Only

	WTPTC_3SLOT	Word	0E F1B2h	Write-Only

	WTPTC_5SLOT	Word	0E F1B4h	Write-Only

	SEQ_RESET	Byte	0E F1B6h	Write-Only

	SEQ_CONTINUE	Byte	0E F1B7h	Write-Only

	RX_STATUS	Byte	0E F1B8h	Read-Only

	CHIP_ID	Byte	0E F1BAh	Read-Only

	INT_VECTOR	Byte	0E F1BCh	Read-Only

	SYSTEM_CLK_EN	Byte	0E F1BEh	Write-Only

	LINKTIMER_WR_RD	Word	0E F1C0h	Read-Only

	LINKTIMER_SELECT	Byte	0E F1C2h	Read-Only

	LINKTIMER_STATUS_EXP_FLAG	Byte	0E F1C4h	Read-Only

	LINKTIMER_STATUS_RD_WR_FLAG	Byte	0E F1C5h	Read-Only

	LINKTIMER_ADJUST_PLUS	Byte	0E F1C6h	Read-Only

	LINKTIMER_ADJUST_MINUS	Byte	0E F1C7h	Read-Only

	SLOTTIMER_WR_RD	Byte	0E F1C8h	Read-Only

		USB Node Registers


	MCNTRL	Byte	FF FD80h	Read/Write	00h

	FAR	Byte	FF FD88h	Read/Write	00h

	NFSR	Byte	FF FD8Ah	Read/Write	00h

	MAEV	Byte	FF FD8Ch	Read/Write	00h

	MAMSK	Byte	FF FD8Eh	Read/Write	00h

	ALTEV	Byte	FF FD90h	Read/Write	00h

	ALTMSK	Byte	FF FD92h	Read/Write	00h

	TXEV	Byte	FF FD94h	Read/Write	00h

	TXMSK	Byte	FF FD96h	Read/Write	00h

	RXEV	Byte	FF FD98h	Read/Write	00h

	RXMSK	Byte	FF FD9Ah	Read/Write	00h

	NAKEV	Byte	FF FD9Ch	Read/Write	00h

	NAKMSK	Byte	FF FD9Eh	Read/Write	00h

	FWEV	Byte	FF FDA0h	Read/Write	00h

	FWMSK	Byte	FF FDA2h	Read/Write	00h

	FNH	Byte	FF FDA4h	Read/Write	C0h

	FNL	Byte	FF FDA6h	Read/Write	00h

	DMACNTRL	Byte	FF FDA8h	Read/Write	00h

CP3BT26

215	www.national.com

Image 215

National CP3BT26 manual Register Name Size Address Access Value After Comments Type, USB Node Registers
