5.1.3 Configuration

5.1.3 Configuration

Standard Printer Configuration

1Printer Cover

2Control Panel

3Paper Guide

4Cover Open Bar

5ON/OFF Switch

1

2

3

4

5

Developer’s Guide: English 63

Image 63

Oki 425D Standard Printer Configuration 1 Printer Cover 2 Control Panel, Paper Guide 4 Cover Open Bar 5 ON/OFF Switch
