4.1.2 LED Indication

No.

1

2

LED

LED 1 (ERROR)

LED 2 (STATUS)

Red

Orange

ON

[Recoverable Alarms]

Slip Load Alarm

→Slip paper was not loaded correctly. Remove it and reload it.

Slip Exit Alarm

→Slip paper did not exit correctly. Remove the Slip paper.

Auto Loading Alarm

→Sprocket paper was not loaded correctly. Set it at the correct position of the Tractor and do the loading operation again.

Auto Parking Alarm

→Sprocket paper did not eject correctly. Do the

parking operation again. If the paper does not move through the Tractor Gear turns, remove it manually. Media Mismatch Alarm

→Media different from the one the printer is trying to print on has been set. Change the print mode or set the correct media.

Cover Open Alarm

→Close the printer cover.

Media has not been loaded (Waiting for loading) state.

→Load the media.

BLINK

Fatal Alarm (see Section 4.1.1) SP Thermal Alarm (blinks simultaneously with LED2)

→The print head area has become hot. As soon as the temperature goes down, the printer recovers automatically.

LF Thermal Alarm

→The LF Motor has become hot. As soon as the temperature goes down, the printer recovers automatically.

Waiting for Media to be removed.

→Remove the media.

SP Thermal Alarm (blinks simultaneously with LED1)

→The print head area has become hot. As soon as the temperature goes down, the printer recovers automatically.

60 OKIPOS 425D
