(2) When the buffer roller lift solenoid (SOL2) is turned ON, the buffer rollers are lifted up, and then
the buffer tray guide motor (M2) opens the buffer tray.
The paper on the buffer tray is thus dropped onto the finishing tray.
At this stage, the patting solenoid (SOL3) is turned ON to drop the paper tapping arm so that the
paper will certainly be dropped onto the finishing tray.
Fig. 3-12
(3) The paper dropped onto the finishing tray is then pulled into the finishing position by the paddles
driven by the paddle motor (M8) and the stack transport rollers-1 and -2 driven by the transport
motor (M7).
The finishing tray paper detection sensor (S12) detects whether paper is on the finishing tray or
not.
The home position of the paddles is detected by the paddle home position sensor (S3).
Fig. 3-13
Buffer tray guide motor
Buffer tray
Buffer tray
Buffer roller
lift solenoid
Patting solenoid
Paper tapping arm
Buffer roller
Paddle motor
Transport motor
Stack transport roller-1
Stack transport roller-2
Finishing tray
paper detection sensor Paddle home position sensor
