When the battery meter or power meter icon is displayed in the taskbar, the icon can also be used as follows.

In Windows 95 and Windows 98—

Task	Procedure

View the total battery power	Rest the cursor over the icon.
remaining in the system.

Enable/disable an on-screen	Left-click the icon, select or clear
critical low-battery warning.	the Enable Low Battery Warning
	check box, then select OK.

Access the Power tab in the	Right-click the icon, select Adjust
Power Properties window.	Power Properties, then press Enter.

Open battery meter in a	Double-click the icon.
popup window.

Display charge information as a percent of a full charge or as the run time remaining.

Left-click the icon, then select your preference in the popup window.

In Windows NT 4.0—

Task	Procedure

View the total battery power	Rest the cursor over the icon.
remaining in the system.

Open the Compaq Power	Double-click or right-click the icon.
Properties window.

Managing Power 5-9
