Solving PC Card Problems

CAUTION: Installing the wrong software can disable the system. Be sure you are installing PC Card device driver software and NOT Card and Socket Services software. If you are uncertain about this, call the PC Card vendor for specific instructions on software installation.

Problem	Possible Cause	Solution

Computer does not beep when a PC Card is inserted

Card is not fully inserted into the slot or is upside down.

Try reinserting the card. Be sure the card is inserted in the correct orientation. Insert the card gently to prevent damage to the pins.

PC Card beeps are	Click on Control PanelÆ
disabled.	double-click the PC Card
	iconÆGlobal Settings tab
	ÆPC Card Sound Effects
	box.

The PC Card device drivers for your card are not installed.

Network cards, audio cards, and other types of PC Cards may need software device drivers in order to function properly. In such cases, refer to the instructions that came with the PC Card or contact the vendor for more information on installing the correct drivers.

Card design or card	Call Compaq Customer
driver may not be	Support for a current list
compatible with the	of Compaq-qualified PC
PCMCIA software.	Cards.

Continued

Troubleshooting 16-19
