O W N E R ’ S M A N U A L • T 8 0 / F T 8 5 / F

1.Increase the treadmill’s speed to 5 km/h (3 mph).

2.Turn both adjustment screws an equal amount, ¼ turn clockwise.

3.Try to slow the belt down by holding onto the handrails and braking as you walk (as if you were walking downhill).

If the belt slips, turn another ¼ turn and repeat the test. When braking heavily the belt may slip. If the belt keeps slipping despite repeated adjustments, please contact your local Tunturi dealer.

MALFUNCTIONS

NOTE! Despite continuous quality control, defects and malfunctions caused by individual components may occur in the equipment. In most cases it’s unnecessary to take the whole device in for repair, as it’s usually sufficient to replace the defective part. Always give the model, serial number of your equipment and in case of malfunctions also conditions of use, nature of malfunction and any error code.

When you encounter unusual behavior from the treadmill, simply turn the power switch off, wait 1 minute and turn the power switch on to reset the treadmill. This should clear incidental errors and ready the treadmill for normal operation again. If after you have reset the treadmill by turning the power switch off and on again, and the treadmill is still not operational, contact your local Tunturi dealer for service.

If you require spare parts, always give the model, serial number of your equipment and the spare part number for the part you need. The spare part list is at the back of this manual. Use only spare parts mentioned in the spare part list.

ERROR CODES

The user interface will display information about operational faults.

SYSTEM CHECK FAILED. Possible motor controller fault. Turn the power switch off, wait 1 minute and turn the power switch on again. If treadmill recovers to normal operation, you may continue to use the treadmill. Otherwise, call the dealer for service. SPEED SENSOR ERROR. Call the dealer for service. MOTOR SPEED ERROR. Ensure correct usage of the treadmill. Do not push the belt with your feet. Turn the power switch off, wait 1 minute and turn the power switch on again. If treadmill recovers to normal operation, you may continue to use the treadmill. Otherwise, call the dealer for service.

MOTOR OVERLOAD. Ensure correct usage of the treadmill. Do not brake the belt. Turn the power switch off, wait 1 minute and turn the power switch on again. If treadmill recovers to normal operation, you may continue to use the treadmill. Ensure the lubrication is sufficient, re-lubricate the running deck if needed. Otherwise, call the dealer for service.

LIFT MOTOR ERROR. Call the dealer for service. LIFT MOTOR OVERLOAD. Ensure correct usage of the treadmill. Do not overload the lift motor by continuously changing the elevation. Turn the power

switch off, wait 1 minute and turn the power switch on again. If treadmill recovers to normal operation, you may continue to use the treadmill. Otherwise, call the dealer for service.

MOVING AND STORAGE

Turn off the power switch and unplug the power cord from the wall and the treadmill. Take hold of the aluminium profile at the rear end of the running base and lift the running base up. Press the horizontal bar in the folding frame with your foot to lock the running base to the lower frame. NOTE! The gas spring is designed to make lifting the running base easier. Always remember to ensure that the running base is locked in the storage position.

Move the T80F / T85F treadmill according to the following instructions: turn the transportation wheels located at the front end of the treadmill so that they point forward, and push the equipment on the transportation wheels. If you wheel the equipment sideways, there is no need to turn the transportation wheels. Once you have moved the treadmill, return the transportation wheels to their sideways position. To release the running base lock, tilt the running base slightly forward while pushing the locking levers in the lower frame to the side with your foot. Lower the treadmill carefully onto the floor.

Move the T80 / T85 treadmill according to the following instructions: stand behind the treadmill and take hold of the aluminium profile at the rear end of the treadmill. Tilt the rear end of the equipment so that it rests on the transportation wheels, and move the equipment by wheeling. Lower the treadmill carefully onto the floor.

NOTE! Transport the treadmill with extreme caution over uneven surfaces, for example over a step. The treadmill should never be transported upstairs using the wheels over the steps, instead it must be carried. We recommend that you use a protective base when transporting the equipment. The running belt needs to be realigned and centered after moving.

To prevent malfunctioning of the treadmill, store it in a dry place with as little temperature variation as possible, protected against dust. Always unplug the treadmill from the electrical outlet when not in use.
