Page 63

PREPARING DOCUMENTS

Setting the resolution and density

You can control the resolution and density of the fax reproduction when sending or copying documents.

jWhat is resolution

Resolution de®nes the quality of the document reproduction. STANDARD is enough for most text documents. Documents with very ®ne print should be set to FINE. Documents with photographs should be set to PHOTO.

jSetting the resolution

To set the resolution, you need to load the document ®rst			STANDARD
To set the resolution, you need to load the document ®rst
(see p. 49).
(see p. 49).	Resolution
¦ STANDARD
¦ STANDARD

Press [Resolution] until STANDARD appears.			FINE
Standard resolution is 3.85 lines/mm.
Standard resolution is 3.85 lines/mm.
When copying, even if you set STANDARD, the
document will automatically be scanned in FINE mode.
document will automatically be scanned in FINE mode.
¦ FINE			PHOTO
Press [Resolution] until FINE appears.
Fine resolution is 7.71 lines/mm.

¦PHOTO

Press [Resolution] until PHOTO appears.

To scan documents that contain photos, use the PHOTO setting. With this setting, areas of the document that contain photos are automatically scanned with 64 levels of grey, rather than just 2 levels, black and white. Photo resolution is 3.85 lines/mm. This results in a much better reproduction of the photograph.

jDensity control

You can adjust the scanning density by changing the DENSITY CONTROL setting in the USER SETTINGS (see p. 85). For light originals choose the DARKER setting. For dark originals choose the LIGHTER setting.

3

51
