Sequential Broadcasting

Sending a document to more than one location

Sequential Broadcasting sends one document to more than one location.

You can send to a total of 31 locations as follows:

One-touch Speed Dialling	=	10 locations
Coded Speed Dialling	=	20 locations
Regular dialling (Numeric buttons dialling)	=	1 location

You can enter the One-touch Speed Dialling and Coded Speed Dialling locations in any order. You simply press the One-touch Speed Dialling button, or press [Coded Dial] followed by the two-digit code (with the numeric buttons).

You can also include one location using Regular dialling. Remember that when using regular dialling, you must press [Start/Copy] after entering the number.

You can send up to 21 A4-size pages (based on the Canon FAX Standard Chart No.1-standard resolution).

1

Feed the document face-down into the
Automatic Document Feeder (ADF).	STANDARD

See Loading the document, p. 49.

You can set the resolution and density. See p. 51.

2

Dial the other party's fax number.

¦You can send to up to 31 locations.

¦Simply enter the numbers one after the other: press the desired One-touch Speed Dialling button or press [Coded Dial] followed by the two-digit code (with the numeric buttons).

¦You can enter only one number directly with the numeric buttons using regular dialling. Remember to press [Start/Copy] after entering the number.

¦You can also press [Redial/Pause] to redial the last number dialled with the numeric buttons.

¦You must press each button within 10 seconds of the preceding one. The fax begins the operation approximately 10 seconds after you press the last button.

TEL= 34567890

3 Press [Start/Copy].

Start/Copy

¦ The fax reads the document into memory and begins sending. Between transmissions, MULTI TRANS. ON displays on the LCD.

¦ To cancel a transmission, press [Stop] during dialling or transmission. All transmissions in the sequence are cancelled.

TX/RX NO.

XXXX

1 sec.

MEMORY INPUT P01

66

Image 78
