SENDING DOCUMENTS

Memory Sending

You can use Memory Sending to send your document. With Memory Sending, the fax quickly scans the document into memory. Then, after it dials the receiving party, it sends the document from memory. This means you do not have to wait for the fax to ®nish sending before you can retrieve your original document.

You can send up to 21 A4-size pages at a time with Memory Sending (based on the FAX Standard Chart No.1- standard resolution).

¦If the memory becomes full while scanning your document, MEMORY FULL is displayed on the LCD. If this should happen, you may need to open the operation panel to remove the document. See Clearing document jams, p. 62. Then try dividing the document into several sections and sending each section individually, or send using Direct Sending or Manual Sending. See p. 57.

The de®nition of an A4-size page for memory storage purposes is based on the Canon FAX Standard Chart No.1.

1		Feed the document face-down into the
1		Feed the document face-down into the				STANDARD
		Automatic Document Feeder (ADF).				STANDARD
		See Loading the document, p. 49.
2		You can set the resolution and density. See p. 51.

		Press [Function].	Function
	Wait a second for TEL REGISTRATION to					SELECT MENU
	appear.
							1 sec.

						TEL REGISTRATION
3

		Press [Send Options].
		Press [Send Options].	Send Options
		Press [Start/Copy].				MEMORY TX
		Press [Start/Copy].
			Start/Copy
			Start/Copy
						TEL=
4

		Dial the other party's fax number.
		Dial the other party's fax number.				TEL=	9876543333
	Use one of the dialling methods described earlier in					TEL=	9876543333
	this chapter. See p. 56.
5
5		Press [Start/Copy].	Start/Copy
	The fax scans the document into memory and					TX/RX NO.		XXXX
	begins sending.
							1 sec.

						MEMORY INPUT P01

5

59
