Network FAX/TEL Switching (New Zealand only)

Telecom N.Z. offers the FaxAbility capability. If you subscribe to this service, your line is assigned two numbers: one for fax and one for phone. When the fax number is called, the network sends a speci®c ringing tone which your unit recognises and automatically handles as a fax call. If the phone number is called, a different ringing tone is sent out from the network so that the call is handled as a voice call. This means that there is no switching delay at the caller's end.

Setting the fax Network

1	Press [Function].	Function
Wait a second for TEL REGISTRATION to			SELECT MENU
appear.
			1 sec.

			TEL REGISTRATION

2	Use [	] or [	] to select RX SETTINGS.	RX SETTINGS
	Press [Start/Copy].			RX SETTINGS
	Press [Start/Copy].			Start/Copy
				ECM RX
3	Use [	] or [	] to select NET. SWITCH.	NET. SWITCH
	Press [Start/Copy].			NET. SWITCH
	Press [Start/Copy].			Start/Copy
				OFF
4	Use [	] or [	] to select ON.	ON
	Press [Start/Copy].			ON
	Press [Start/Copy].			Start/Copy
5	Press [Stop].			Stop
				Stop
