Station Data

Target Point

Enter station point number and height of the instrument.

FREST\ STATION DATA

14:03

Station no. :

MC

1

Inst.Height :

1.555

m

αNUM

HELP

CONF

F1

F2

F3

F4

F5

F6

Proceed to define the target points.

Start the "CONFIGURATION"

Alpha-numerical/numerical input.

Enter the target point number and height of the reflector.

FREST\

TARGET POINT

14:03

Station no. :

MC

1

Refl.Height:

1.555

m

CALC

LIST

<--

-->

αNUM

HELP

F1

F2

F3

F4

F5

F6

Run the calculation. Note, the key will be assigned after sufficient measurements were taken to calculate a position.

80

TPS-System 1000 Programs-2.3.1en

© Leica
