Section V - Windows Printing
Assign Print Server IP Address
1.Using OkiNet for IP, assign the print server an IP address; for example, 10.10.10.2.
Note: For more information on using
OkiLAN 6010e TCP/IP, see OkiNet for
TCP/IP.
Add LPR Printer
1.From the Windows NT Print Manager Printer menu, select Create Printer.
2.In the Create Printer window select:
∙Printer Name
∙Driver
∙Description
3.At the Print prompt, select Other.
4.From the Print Destinations window, select LPRPort.
5.From the Add LPR Compatible Printer window, enter the print server’s IP address or name (if you are using DNS or WINS) for the host name prompt.
6.Enter a number indicating the desired print server’s output port for the printer name prompt and click OK. For example, for port
1enter P1, for port 2 enter P2, etc.
7.Click OK from the Create Printer window to add the printer.
Windows Printing
OKI OkiLAN 6010e User’s Guide | V - 19 |
