Unit 4: Printer Configuration

WIRELESS LOCAL AREA NETWORK (WLAN) INTERFACE MODE (TABLE 4-9)

MENU		DESCRIPTION
	Is the menu selection screen for the INTERFACES Mode.
INTERFACES
Ignore CR/LF
Item No. Check
BCC Check
History Buffer
Comm. Protocol
Host Interface
ETHERNET PORT
ETHERNET SETTING
WLAN ADDRESS
WLAN SETTING
Parallel Port
USB Port
Serial Port
Printer Mgt
	Determines whether the print data code will be deleted. Hexadecimal graphic data will not be
	deleted.
Ignore CR/LF	•	No - factory default. Will not be deleted.
No*
	•	Yes - will delete all carriage returns (CR) and line feed (LF) commands in the data stream -
		including graphics and 2D barcodes.
	This menu screen is only available when Status 5 is selected for Bi-Com interface. Determines
	how the printer will react if the item number (ID Command) is set to be processed by the printer.
	•	Disable - factory default. Does nothing regardless of whether the item number is included in
		the format.
Item No. Check
Disable*	•	Cancel - errors when the incorrect item number is being accessed. When the printer is
		brought back online from the error, by pressing the Line key, the incorrect job is canceled.

•Resume - errors when the incorrect item number is being accessed. When the printer is brought back online from the error, by pressing the Line key, the incorrect job is canceled.

Block-Check-Code Algorithm Check. Only available when Status 5 is selected for Bi-Com interface. Determines how the printer will react if the BCC is set to be processed by the printer.

	•	Disable - factory default. Does nothing regardless of whether the BCC is included in the
		format.
BCC Check
Disable*	•	Cancel - errors when the incorrect BCC is being accessed. When the printer is brought back
		online from an error, by pressing the Line key, the incorrect job is printed.
	•	Resume - errors when the incorrect item number is being accessed. When the printer is
		brought back online from the error, by pressing the Line key, the incorrect job is canceled.

The history buffer stores a history of printer statuses. Is only available when Status 5 is selected for Bi-Com interface.

	•	Temporary - factory default. Store the history buffer in the internal RAM. This memory is
History Buffer
Temporary*		deleted when the printer’s power is turned off.
	•	Permanent - stores the history buffer in Flash (internal or optional) Memory. This memory
		can only be cleared through the printer’s display.

GL408-412e Operator’s Manual 4-57
