Setting up auto-run

Level-triggered auto-on setting

Level- Explanation of Settings

Triggered

B. Action



After selecting specific filter mode settings, the instrument is set to trigger







based on Run/Pause mode or Run/Stop mode.







C.Source The source can be set to Meter 1, Meter 2, filters, curve, external trigger, timed run trigger mode, and a delay. which are explained below:

Broadband: When selecting Meter 1 or Meter 2 for the triggering source, you then specify a specific value in the “level” field such as 85dB.

Filters: Octave band filters are selectable as a triggering source such as:

12.5Hz, 16Hz, 20Hz through 20KHz. Note: this is only available if they have purchased the 1/1 or 1/3 features. To select a filter, select a an octave band value (.i.e. 10KHz) in the source field. Then, select a Level value (i.e., 90dB).

Delay: When selecting Delay with a specified time value, it will trigger the auto-run after the timed-delay surpasses. (This is similar to setting a delay on a camera.) To select “Delay”, select the Source as “Delay” and for Level select a specific time value (the range is from 00:01 seconds to 59:00 minutes).

Curve: If the curves feature has been purchased, you have the option of selecting one of the 4 captured curves to trigger a run. To select a captured curve, set the Source as “Curve” and then change the “Level” field to one of the following: CAP-1, CAP-2, CAP-3, or CAP-4.

EXT: External Trigger feature is triggered by the digital input on the curve indicator. To select external trigger, select “EXT” as the source field, and select “LO” for the level field.

TIMED: When selected as the RUN trigger, it will cause a delay of specified direction between the timed RUN button is pressed and the time the RUN actually starts. When selected as the PAUSE/STOP trigger, it sets a run length. To select under the Source and Pause fields, chose Timed. Next, select a timed value (or duration) in the Level field. (This is formatted as hours:minutes:seconds.)

D. Level

The level field corresponds with your selection from the Source field and is





explained under “C. Source”.



Table 4-1: Level Triggered Auto-On settings explained

5.To select the Mode, press Enter repeatedly until you are viewing either Level On/Off or Windowed.

6.To move to the next field, press the Down arrow.

7. To set the Action, press Enter

repeatedly until you are viewing

either Run/Pause or Run/Stop.



8.To move to the next field press the Down arrow.

9.To change the Source, press the right arrow. To select one of the five

Sources (as explained above in Table 4-1), press Enter

repeatedly

until you are viewing the appropriate feature.





Models SE and DL
