Cisco Systems 3825 show cem circuit

A-74

Cisco 3825 Mobile Wireless Edge Router Software Configuration Guide

OL-15667-03

Appendix A Cisco 3825 Mobile Wireless Edge Router RAN-O Command Reference

show cem circuit

show cem circuit

To display a summary of circuit emulation (CEM) circuits, use the show cem circuit command in the

privileged EXEC mode.

show cem circuit [cem-id]

Syntax Description

Command Modes Privileged EXEC

Command HistoryGl

Examples The following is an example of the output generated by this command.

Router# show cem circuit

CEM Int. ID Ctrlr Admin Circuit AC

--------------------------------------------------------------

CEM0/0/0 0 UP UP Enabled UP

CEM0/0/1 1 UP UP Enabled UP

CEM0/1/0 2 UP UP Enabled UP

CEM0/1/1 3 UP UP Enabled UP

CEM0/2/0 4 UP UP Enabled UP

CEM0/2/1 5 UP UP Enabled UP

Router# show cem circuit 5

CEM0/2/1, ID: 5, Line: UP, Admin: UP, Ckt: Enabled

Controller state: up

Idle Pattern: 0xFF, Idle cas: 0x8

Dejitter: 4, Sample Rate: 1, Payload Size: 192

Framing: Framed, (DS0 channels: 1-24)

CEM Defects Set

None

Signalling: No CAS

RTP: No RTP

Ingress Pkts: 527521938 Dropped: 0

Egress Pkts: 527521938 Dropped: 0

CEM Counter Details

Input Errors: 0 Output Errors: 0

Pkts Missing: 0 Pkts Reordered: 0

Misorder Drops: 0 JitterBuf Underrun: 0

Error Sec: 0 Severly Errored Sec: 0

Unavailable Sec: 0 Failure Counts: 0

Pkts Malformed: 0

cem-id (Optional) Identifies the circuit configured via the cem-group configuration

mode.

Release Modification

12.4(12)MR2 This command was introduced.
