HP 8568B 12. Amplitude, Fidelity Test

	12. Amplitude Fidelity Test
12. Amplitude	(For instruments with Option 857, refer to Chapter 5.)
Fidelity Test
Related Adjustment	Log Amplifier Adjustments
Specification	Log:

Incremental

ho.1 dB/dB over 0 to 80 dB display Cumulative

3 MHz to 30 Hz Resolution Bandwidth

<kl.O dB max over 0 to 80 dB display (20 - 30°C). 5% 1.5 dB max over 0 to 90 dB display

Linear:

f3% of Reference Level for top 9-l/2 divisions of display

Description Amplitude fidelity in log and linear modes is tested by decreasing the signal level to the spectrum analyzer in 10 dB steps with a calibrated signal source and measuring the displayed amplitude change with the analyzer’s MARKER A function.

SIGNAL ANALYZER

SYNTHESIZERf LEVEL

GENERA OR

ADAPTER

Figure 2-21. Amplitude Fidelity Test Setup

P e r f o r m a n c e T e s t s 2-41
