AI2524 Router Card User’s Manual

Router# co?

configure connect copy



z Enter the configure command followed by a space and a ques-



tion mark (?) to list the command's keywordsand a brief explana-



tion:





Router# configure ?



memory

Configure from NV memory

network

Configure from a TFTP network host

terminal

Configure from the terminal

<cr>







The <cr> symbol by itself indicates there are no more keywords or ar- guments. Press <Enter> to execute the command.

zEnter the terminal keyword to enter configuration mode from the terminal:

Router# configure terminal

Enter configuration commands, one per line.End with CNTL/Z

Router(config)#

zEnter the access-listcommand followed by a space and question mark (? ) to list the command's keywords:

Router(config)# access-list ?

<1-99>

IP standard access list

<100-199>

IP extended access list

<1000-1099>

IPX SAP access list

<1100-1199>

Extended 48-bit MAC address access list

<200-299>

Protocol type-code access list

<300-399>

DECnet access list

<400-499>

XNS standard access list

<500-599>

XNS extended access list

<600-699>

Appletalk access list

<700-799>

48-bit MAC address access list

<800-899>

IPX standard access list

<900-999>

IPX extended access list





z Enter the access list number 99. Then, enter another question mark (?) to see the arguments and brief explanations for the key- word:

Page 4-20

August 1997



2524UM
