Chapter 6: Using the System Configuration Dialog

32K bytes of non-volatile configuration memory.

8192K bytes of processor board System flash (Read ONLY) Notice: NVRAM invalid, possibly due to write erase.

--- System Configuration Dialog ---

At any point you may enter a question mark '?' for help. Refer to the 'Getting Started' Guide for additional help. Use ctrl-c to abort configuration dialog at any prompt. Default settings are in square brackets '[]'.

Would you like to enter the initial configuration dialog? [yes]:

3.Press <Enter> or type yes to begin the configuration process.

4.When the System Configuration Dialog asks whether you want to view the current interface summary, press <Enter> or type yes.

:

First, would you like to see the current interface summary? [yes]:

Any interface listed with OK? value "NO" does not have a valid configuration

Interface

IP-Address

OK?

Method

Status

Protocol

Ethernet0

unassigned

NO

not set

up

down

BRI0

unassigned

NO

not set

up

up

Serial0

unassigned

NO

not set

down

down

Serial1

unassigned

NO

not set

down

down













5.Configure the global parameters. Choose which protocols to sup port on the Ethernet interface. For IP installations, you can press <Enter> to accept the default values (in brackets) for most of the questions. A typical configuration is:

:

Configuring global parameters:

Enter host name [Router]:

Next, you are prompted to enter an enable secret password. There are two types of privileged-level passwords:

zEnable secret password (a very secure, encrypted password

zEnable password (a less secure, nonencrypted password)

The enable password is used when the enable secret password does not exist.

For maximum security, be sure the passwords are different. If you enter the same password for both, the router will accept your entry, but will display a warning message indicating that you should enter a dif- ferent password.

August 1997

Page 6-3

2524UM
