AIS AI2524 - page 87

Chapter 5: Using AutoInstall

August 1997 Page 5-21

2524UM

Note: If any problems exist with the configuration file pointed to

in NVRAM, or if the ignore NVRAM bit is set in th

configuration register, the router en te r s t h e streaml ined

setup command facility. Ref er to Use the Streamlined

Setup Facility, for more information.

This example shows how to use the setup command facility to config-

ure interface serial 0 and to add ARAP and IP/IPX PPP support on the

asynchronous interfaces:

Router# setup

---System Configuration Dialog---

At any point you may enter a q uest ion mark '?' for hel p.

Use ctrl-c to abort configuration dialog at any prompt.

Default settings are in square bracket s ' []'.

Continue with configuration dialog? [yes]:

First, would you like to see the current interface summary? [yes]:

Interface IP-Address OK? Method Status Protocol

Ethernet0 172.16.72.2 YES manual up up

Serial0 unassigned YE S not set down down

Serial1 172.16.72.2 YES not set up up

Configuring global parameters:

Enter host name [Router]:

The enable secret is a one-way cryptographic secret used instead of the e nable

password when it exists.

Enter enable secret [<Use current secr et>] :

The enable password is used when t here is no enable secret and when using older

software and some boot images.

Enter enable password [ww]:

Enter virtual terminal password [ww]:

Configure SNMP Network Management? [yes]:

Community string [public]:

Configure DECnet? [no]:

Configure AppleTalk? [yes]:

Multizone networks? [no]: yes

Configure IPX? [yes]:

Configure IP? [yes]:

Configure IGRP routing? [yes]:

Your IGRP autonomous system number [15]:
