AI2524 Router Card User’s Manual

Enter Commands Using the Command Field

Entering the command in the command field is just like entering it at a terminal console. If you are uncertain of the options available for particular command, type a question mark (?).

For example, typing show ? in the command field displays the pa- rameters for the show command. The Web Browser interface displays the parameters as hypertext links. To select a parameter, click one of the links or enter the parameter in the command field.

Enter Commands Using the URL Window

You can issue a command using the Universal Resource Locator (URL) window for the Web browser.

For example, to execute a show configuration command on a router named example, you would enter this in the URL window:

http://example/exec/show/configuration

The Web browser then displays the configuration for the exampl router. To save effort, modify the URL in the URL window in the browser control bar instead of retyping the entire URL.

The difference between entering a command in the command field and entering a command in the URL window is that in the URL window, command modes and options should be separated by slashes, not spaces.

Page 4-30

August 1997



2524UM
