AIS AI2524 Page 5-26 August 1997

AI2524 Router Card User’s Manual

Page 5-26 August 1997

2524UM

Interface Async9

ipx network C

ip unnumbered Ethernet0

async default ip address 172.16.72.12

async mode interactive

Interface Async10

ipx network D

ip unnumbered Ethernet0

async default ip address 172.16.72.13

async mode interactive

Interface Async11

ipx network E

ip unnumbered Ethernet0

async default ip address 172.16.72.14

async mode interactive

Interface Async12

ipx network F

ip unnumbered Ethernet0

async default ip address 172.16.72.15

async mode interactive

Interface Async13

ipx network 10

ip unnumbered Ethernet0

async default ip address 172.16.72.16

async mode interactive

Interface Async14

ipx network 11

ip unnumbered Ethernet0

async default ip address 172.16.72.17

async mode interactive

Interface Async15

ipx network 12

ip unnumbered Ethernet0

async default ip address 172.16.72.18

async mode interactive

Interface Async16

ipx network 13

ip unnumbered Ethernet0

async default ip address 172.16.72.19

async mode interactive

router igrp 15

network 172.16.0.0

end
