Downloading Software

The Software Update Utility

Figure 16-2. Scheduling the Software Update

Scheduling the Software Update

To update the device(s) immediately, click the radio button Start Now. The device update proceeds and the device is automatically rebooted when the update is finished. Alternatively, you can schedule a day and time within a one week period for the update to occur. Click on the Schedule for radio button and select Today, Tomorrow, or a day of the week, then select a time. Click on Next.

Your selections and schedule are displayed in the next page. Click on Finish to proceed with these selections. If you click on Cancel to cancel your selections you are returned to the first page of the Software Update Utility.

16-5
