Canon B45 Redialing when the line is busy

SENDING DOCUMENTS

4

4-9

There are two methods of redialing: manual redialing and automatic redialing. This section

explains these two methods.

Manual redialing ______________________________

Press [Redial/Pause] to dial the last number you dialed with the numeric buttons. (This starts

redialing regardless of whether automatic redialing is enabled.)

■ Canceling manual redialing

To cancel manual redialing, press [Stop].

Automatic redialing __________________________

■ What is automatic redialing?

When you are sending a document and the receiving party’s line is busy, the fax waits the

specified time and then dials the same number again. You can set the fax to redial several times if

previous attempts fail because of a busy signal.

Automatic redialing can be turned off and on. The number of redialing attempts and the time

interval between attempts can also be adjusted (see AUTO REDIAL, p. 7-3).

If all redialing attempts are unsuccessful, the fax will cancel the transmission.

When automatic redialing is in use, the LCD displays AUTO REDIAL while it is waiting to

redial.

■Canceling automatic redialing

Automatic redialing cannot be canceled with the [Stop] button while the fax is waiting to redial.

1 Wait until the fax begins redialing.

2 Press [Stop].

nIf you want to cancel a memory-sending transmission while the fax is waiting to redial, you will

have to delete the document from memory (see p. 4-15).

Redialing when the line is busy
