Dell R300 owner manual Rank 3, 4 DIMM2A and DIMM2B Rank 5, 6 DIMM3A and DIMM3B

Rank 3, 4: DIMM2_A and DIMM2_B

Rank 5, 6: DIMM3_A and DIMM3_B

The memory modules must be installed in identical pairs in configurations that have more than one memory module. For example, if socket DIMM1_A contains a 512-MB memory module, then the second memory module to be installed must be a 512-MB memory module in socket DIMM1_B.

Table 3-1 shows examples of different memory configurations, based on the following guidelines:

•The minimum memory configuration is 512 MB.

•If only one memory module is installed, it must be installed in the DIMM1_A socket.

•A rank must contain identical memory modules.

•Install memory modules in rank 1, 2(DIMM1_x) before installing memory modules in rank 3, 4 (DIMM2_x), and install memory modules in rank 3, 4 before installing rank 5, 6 (DIMM3_x).

•Configurations of three or five memory modules are not supported.

Table 3-1. Sample Memory Module Configurations

Total
Memory	DIMM1_A	DIMM1_B	DIMM2_A	DIMM2_B	DIMM3_A	DIMM3_B
512 MB	512 MB
1 GB	512 MB	512 MB
1 GB	1 GB
2 GB	512 MB	512 MB	512 MB	512 MB
2 GB	1 GB	1 GB
3 GB	512 MB	512 MB	512 MB	512 MB	512 MB	512 MB
4 GB	1 GB	1 GB	1 GB	1 GB
4 GB	2 GB	2 GB
6 GB	1 GB	1 GB	1 GB	1 GB	1 GB	1 GB
8 GB	2 GB	2 GB	2 GB	2 GB
