Figure 3-4. Installing and Removing the System Cover

1

2







3

1

latch

2

latch release lock

3

alignment J hooks





System Board Shroud

The system board shroud covers the processor, heatsink, memory modules, and system battery and provides air flow to these components. Airflow is facilitated by the cooling fan modules, which are positions directly behind the system board shroud.

70

Installing System Components

Page 70
