A
Printer Specifications
Environmental Specifications
Physical Dimensions
Height | 7.87 in (200 mm) |
|
|
Width | 15.75 in (400 mm) |
|
|
Depth (body) | 17.52 in (445 mm) |
|
|
Weight (with toner cartridge) | 24.5 lb (11.1 kg) |
|
|
|
|
Electrical Specifications
Power Requirements | 100/120V (+/- 10%) 50/60Hz (+/- 2Hz) | 220/240V (+/- 10%) 50/60 Hz (+/- 2Hz) | |
| 127 Volts NOM |
| |
|
|
| |
Power Consumption (typical for 6P and | During printing – 175 W (average) | During printing – 175 W (average) | |
6MP) |
|
| |
During standby – 8 W (instant power | During standby – 8 W (instant power | ||
| |||
| save) | save) | |
| During power save mode – 8 W | During power save mode – 8 W | |
|
|
| |
Minimum recommended circuit capacity | 5 Amps | 2.4 Amps | |
|
|
| |
|
|
|
Environmental Specifications
Item | Operating Printing |
| Storage/Standby |
|
|
|
|
Temperature | 59° to 89° F (15° to 32.5° C) | - | 4° to 104° F |
(printer and toner cartridge) |
|
|
|
|
|
|
|
Relative humidity | 10% to 80% |
| 10% to 90% |
|
|
|
|
|
|
|
|
Acoustic Emissions (Per ISO 9296)
Printer State | Operator Position | Bystander (1m) | Sound Power |
|
|
|
|
Printing | LpAm 54dB(A) | LpAm 48dB(A) | LWAd 6.3 bels(A) |
|
|
|
|
Power Save* | LpAm <21dB(A) | LpAm <21dB(A) | LWAd <3.6 bels(A) |
|
|
|
|
*In this mode, the printer is essentially quiet.
EN | Printer Specifications |
