Solving Keyboard and Mouse ProblemsTable 5-30Keyboard and Mouse Problems

Problem

Cause

Solution

Keyboard commands and typing Keyboard connector is not

are not recognized by the properly connected. workstation.

1.Shut down the workstation.

2.Reconnect the keyboard to the back of the workstation and restart the workstation.

	Program in use has stopped	Shut down the workstation using the mouse and then
	responding to commands.	restart the workstation.

	Keyboard needs repairs.	Replace the keyboard.

	Keyboard key is stuck down.	Remove any debris from the keyboard.

	Workstation is in Standby	Press the power button to resume from Standby
	mode.	mode.

WARNING! When attempting to resume from Standby mode, do not hold down the power button for more than four seconds. Otherwise, the workstation will shut down and you will lose your data.

Cursor will not move using the	The Num Lock key	Press the Num Lock key. The Num Lock light
arrow keys on the keypad.	might be on.	should not be on if you want to use the arrow keys.
		The Num Lock key can be disabled (or enabled)
		in Computer Setup.

Mouse does not respond to	Mouse connector is
movement or is too slow.	not properly plugged into
	the back of the workstation.

1.Shut down the workstation using the keyboard.

2.Plug the mouse connector into the PS/2 mouse connector slot in the workstation and restart the workstation.

You need to increase mouse acceleration.

1.In Windows, click Start > Control Panel and double-click Mouse.

2.Select the Motion tab and adjust the speed.

Program in use has stopped responding to commands.

Shut down the workstation using the keyboard and then restart the workstation.

	Mouse needs repairs.	Replace the mouse.

	Workstation is in Standby	Press the power button to resume from Standby
	mode.	mode.

CAUTION: When attempting to resume from Standby mode, do not hold down the power button for more than four seconds. Otherwise, the workstation will shut down and you will lose your data.

Mouse will only move vertically Mouse roller ball is dirty. or horizontally, or movement is

jerky.

Remove roller ball cover from the bottom of the mouse and clean it.

154 System Diagnostics and Troubleshooting
