HP xw9300 Cleaning the Mouse

Cleaning the Mouse

Follow all safety precautions stated earlier before cleaning the mouse.

To clean the mouse:

•Clean the mouse ball by first removing the retaining plate and the ball from the housing.

•Pull out any debris from the ball socket and wipe the ball with a clean, dry cloth before reassembly.

Routine Care F

Cleaning the Mouse 201
