HP xw9300 LED Color Definitions, Table 5-21 LED Color Definitions

LED Color Definitions

An LED light exists on the front panel of your workstation. The following table describes what each color signifies.

Table 5-21LED Color Definitions

LED State	LED Color	System Status

Solid	Green	System is on.

Blinking	Green	System is in Standby.

Solid or Blinking	Red	System has error.

None	No light	System is in Hibernate or it is off.
