Operation

To print the logs:

M 52 OK - PRINT / LOGS

The incoming and outgoing logs are printed on the same page.

Contents

PRINTING THE FUNCTIONS LIST

You may print the functions list of your machine at any time.

To print the functions list:

M 51 OK - PRINT / FUNCTIONS LIST

PRINTING THE MACHINE SETTINGS

At any moment, you may print the list of your parameter settings to control any changes possibly made to the default parameters.

Printing the machine settings:

M 54 OK - PRINT / SETUP

Your machine prints the list of stored parameters.


		PROGRAMMING SPEED DIALS

	You may programme speed dials of keys (for example, to send a fax directly to one or multiple
	group dial, to call this group dial or to get access to a specific menu, etc.).
	This sequence is registered in one of the keys F1 or F2 (as you want).
	Then, by pressing one of these keys, you will execute the registered sequence.
NOTE	: By default, Scan to PC function is programmed on F1 key and Scan to FTP function is programmed
	on F2 key.
	To register a sequence (for example, in key F1).
	Press key MENU, then F1: you will enter the menu option
	From this moment, all the key pressings are memorized in the key F1.
	Press key F1 to register the sequence if you are still in the menus. The sequence
	memorizing is automatic if you have already exited the menu.
	Example: to memorize a fax sending to various group dial in key F1:
	Press keys MENU then F1.
	Press keys 3, 1 then OK.
	Enter the group dial fax machine number.
	Press key and enter the second group dial fax machine number or subscribers list.
	- 81 -
