text box without pressing the Enter key will cause the setting to return to the number that it was before a change was attempted. Alternatively, click and drag across the number in the box to highlight the number in it. Type the new setting and press the Enter key when finished.
Using the UP/DOWN Arrows
To increase the level, click on the up arrow. To decrease the level attenuation, click on the down arrow. The amount of increase or decrease is controlled by the fine/coarse control.
Using the Filter Tool
Click on the triangle associated with the filter band that needs its center frequency adjusted. While holding the mouse button down, drag the mouse from side to side. A display indicating the current center frequency will appear. When the desired frequency is reached, release the mouse button. Please note that exact center frequencies may be impossible to obtain using this method.
Boost/Cut
The Boost (gain) or Cut (attenuation) of a filter can be adjusted three ways:
Using the Text Box
Click in the box. Using the Back Space and/or Delete keys erases the current entry and enters the new level. Be sure to press the Enter key after the entry is made. Clicking outside the text box without pressing the Enter key will cause the setting to return to the number that it was before a change was attempted. Alternatively, click and drag across the number in the box to highlight the number in it. Type the new setting and press the Enter key when finished.
Using the UP/DOWN Arrows
To increase the level, click on the up arrow. To decrease the level attenuation, click on the down arrow. The amount of increase or decrease is controlled by the fine/coarse control.
Using the Filter Tool
Click on the red dot on the active filter band. While holding down the mouse button, move the mouse up and down. A display will appear indicating the amount of boost or cut. When the desired level is reached, release the mouse button.
Bandwidth
The Bandwidth of the filter can be adjusted in three ways:
Using the Text Box
Click in the box. Using the Back Space and/or Delete keys erases the current entry and enters the new level. Be sure to press the Enter key after the entry is made. Clicking outside the text box without pressing the Enter key will cause the setting to return to the number that it was before a change was attempted.
Filter bands can be stacked for increased boost/cut.
